Mermin's example of Bell's inequality

Bell, Mermin, Tsirelson

I recently came across an exceptionally clear discussion of Bell's inequalities:

[pdf] Mermin, N.D., "Bringing home the atomic world: Quantum mysteries for anybody", Am. J. Phys. 49(10), pp. 940-943, (1981).

Bell inequalities are conditions obeyed by random variables with classical probability distributions, and thus by any (local) hidden variable theory. Quantum mechanics correctly predicts that physical systems may violate these conditions. However there are weaker versions of the Bell inequalities, the so-called Tsirelson bound, that even quantum mechanical systems must obey.

After reading Mermin's beautiful paper, I decided to work out a few extra details, including the Tsirelson inequality for the class of systems he describes. It's totally trivial but I couldn't find it written down explicitly anywhere so I thought I would write about it here.

A game

Suppose you are invited to play a game against a team consisting of Alice and Bob, who are each in separate rooms and cannot communicate with each other. The game consists of a sequence of turns. On each turn, you construct a pair of boxes and give one to each of Alice and Bob. On these boxes there is:
• a three-way selector switch, with positions labelled 1, 2, 3,
• a push button,
• a light, initially off.
Alice and Bob are free to set the selector switches on their boxes to any of the three positions, after which they press the button. The boxes must be such that:
1. when the button is pressed, the light will permanently illuminate either red or green,
2. if Alice and Bob happen to have selected the same position for their selector switches, the lights on their boxes must both illuminate to the same colour.
After many turns of the game, for any $1 \le i, j \le 3$, we can take all those turns where Alice selected position $i$ and Bob selected position $j$, and let $p_{ij}$ be the proportion of times that their lights illuminated to the same colour. The game continues until we have a large number of turns for each of these nine combinations. (Let's say Alice and Bob lose if this doesn't happen before a million turns.) We thus have a matrix: $$\left[\begin{array}{ccc} p_{11} & p_{12} & p_{13}\\ p_{21} & p_{22} & p_{23}\\ p_{31} & p_{32} & p_{33}\\ \end{array}\right]$$ Note that by condition (ii) $p_{11} = p_{22} = p_{33} = 1$.

You should be able to think of a strategy for creating boxes for which $p_{ij} = \frac{1}{3}$ (in the limit) when $i \ne j$. However the rule for winning the game is that you must come up with a strategy for which $p_{ij} \lt \frac{1}{3}$ when $i \ne j$.

Would you play this game?

The game's Bell inequality

For a given turn of the game, classically we can represent the physical system of the two boxes as a measure space on which we have random variables $A_1, A_2, A_3, B_1, B_2, B_3$. The variable $A_i$ represents the colour to which the Alice's light would have illuminated if she had had her selector switch in position $i$ when she pressed the button. Similarly, with $B_i$ but for Bob.

Now encode the colour red as $-1$ and green as $+1$. This means that the product of two of these random variables is $+1$ if the colours agree and $-1$ otherwise, and thus taking expectations: $$\mathbb{E}(A_i B_j) = p_{ij}\cdot 1 + (1 - p_{ij})\cdot (-1) = 2p_{ij} - 1.$$

Finally consider the random variable: $$\begin{array}{crccccc} X = & - A_1 B_1 & + & A_1 B_2 & + & A_1 B_3 & +\\ & A_2 B_1 & - & A_2 B_2 & + & A_2 B_3 & +\\ & A_3 B_1 & + & A_3 B_2 & - & A_3 B_3 &\\ \end{array}$$ Now calculate: $$\mathbb{E}(X) = -9 + 2\sum_{i \ne j}p_{ij}.$$ Furthermore, by condition (ii) of the game, we must have $A_i = B_i$ and thus $p_{ij} = p_{ji}$ and so we can simplify the above to: $$\mathbb{E}(X) = -9 + 4(p_{12} + p_{13} + p_{23}).$$ However from the definition of $X$ we have: $$|X| \le |-B_1 + B_2 + B_3| + |B_1 - B_2 + B_3| + |B_1 + B_2 - B_3| \le 5.$$ In particular $X \ge -5$ and thus: $$\mathbb{E}(X) \ge -5.$$

Putting everything together we have $-9 + 4(p_{12} + p_{13} + p_{23}) \ge -5$ and thus finally: $$p_{12} + p_{13} + p_{23} \ge 1.$$ From this we must have $p_{ij} \ge \frac{1}{3}$ for some $i \ne j$ and so if you are playing the game in a classical universe, you cannot win!

(Note that the above does not assume any physical non-determinism, the measure space is just a mathematical tool to free us from having to make assumptions about the details of the physical system. I have sketched an alternate proof that avoids using this language in the appendix.)

Playing in a quantum-mechanical universe

The argument in the previous section is very general and if you don't know quantum mechanics, it is very hard to see how it fails to model reality. It should thus be very surprising to learn that quantum mechanics correctly predicts the existence of a strategy for winning the game by building boxes for which $p_{ij} = \frac{1}{4}$ for all $i \ne j$ (and of course $p_{ii} = 1$)!

The details of the quantum system are irrelevant for everything else I say but for completeness I'll give a brief sketch of the setup that Mermin describes.

The boxes can be built by having each box contain one of a pair of spin-$\frac{1}{2}$ particles entangled in a so-called singlet state. The selector switch picks an angle from $\{0, \pm 2\pi/3\}$ at which to measure a component of the particle's spin, the button carries out the measurement, and the light indicates the result. An easy calculation with Pauli matrices reveals that if the angle difference between Alice and Bob's selectors is $\theta$ then the probability that their results disagree is $\cos^2(\theta/2)$. By having opposite colour-conventions on the two boxes, we get the required behaviour.

The game's Tsirelson bound

The false assumption that allowed us to derive the game's Bell inequality is that the value of $A_i$ is well-defined if Alice actually used setting $j \ne i$ for a given turn of the game (likewise for Bob). Obviously no experiment could ever falsify the non-existence of these values and indeed quantum mechanically these values do not exist. Instead of random variables, we have operators from which we may obtain a probability distribution of possible values, but there is no actual value except what is measured.

Thus, quantum mechancially we still have $A_i, B_i$ but they are now operators. Even though these operators do not all commute (e.g., $A_1 A_2 \ne A_2 A_1$) we do still have:

• $A_i B_j = B_j A_i$, because these measurements are space-like separated,
• $A_i^2 = B_i^2 = I$, because they are diagonalisable operators with eigenvalues $\pm 1$.

As before, set: $$\begin{array}{crccccc} X = & - A_1 B_1 & + & A_1 B_2 & + & A_1 B_3 & +\\ & A_2 B_1 & - & A_2 B_2 & + & A_2 B_3 & +\\ & A_3 B_1 & + & A_3 B_2 & - & A_3 B_3, &\\ \end{array}$$ but now also define: \begin{align} P &= \frac{1}{2}(-A_1 + A_2 + A_3) + B_1,\\ Q &= \frac{1}{2}( A_1 - A_2 + A_3) + B_2,\\ R &= \frac{1}{2}( A_1 + A_2 - A_3) + B_3,\\ S &= \frac{1}{2}( A_1 + A_2 + A_3). \end{align} Then calculate: \begin{align} P^2 + Q^2 + R^2 + S^2 &= X + A_1^2 + A_2^2 + A_3^2 + B_1^2 + B_2^2 + B_3^2,\\ &= X + 6I. \end{align} Since $P$ is self-adjoint, $\mathbb{E}(P^2) \ge 0$ and likewise for $Q, R, S$. We thus obtain: $$\mathbb{E}(X) \ge -6.$$ This is the Tsirelson bound for this system. Note that it is weaker than what we obtained when using the stronger classical assumptions since it has $-6$ instead of $-5$.

We can calculate $\mathbb{E}(X)$ for Mermin's setup. This has $p_{ij} = \frac{1}{4}$ for all $i \ne j$ and $p_{ii} = 1$, and thus $\mathbb{E}(A_iB_j) = -\frac{1}{2}$ for $i \ne j$ and $\mathbb{E}(A_iB_i) = 1$, so that: $$\mathbb{E}(X) = -3 + 6(-\frac{1}{2}) = -6.$$ We thus see that the Tsirelson bound is tight. Equivalently, we get: $$p_{12} + p_{13} + p_{23} \ge \frac{3}{4},$$ and so we see that Mermin's system is extremal.

Formal verification

I cannot finish without mentioning that the Mathlib project currently has an open PR formalising some Bell and Tsirelson inequalities!

Appendix

The lemmas here sketch an alternate approach to Bell's inequalities derived above in the case $k = 2$, $m = 3$.

Lemma 1 For natural numbers $k, l, m$, let $A$ be an $l \times m$ matrix whose values belong to a $k$-element set. For any $i, j$, with $1 \le i, j \le m$, let $c_{ij}$ be the number of rows of $A$ for which the value in column $i$ matches the value in column $j$. Then if $k < m$, there exist $i, j$ with $i \ne j$ such that: $$c_{ij} \ge \frac{l}{m \choose 2}.$$

Proof (sketch) Construct a new matrix $\hat A$ of dimensions $l \times {m\choose 2}$ whose rows correspond to those of $A$ and whose columns correspond to unordered pairs of distinct columns of $A$. The values in $\hat A$ are 0 or 1 according to whether the corresponding pair of values in $A$ match.

Let $S$ be the number of 1s in $\hat A$. By the pigeon hole principle, since $k < m$ there is at least one repeated value in any row of $A$ and thus at least one 1 in each row of $\hat A$. Counting $S$ row-wise, we thus have: $$l \le S.$$ On the other hand, counting $S$ column-wise gives: $$S = \sum_{i \ne j}c_{ij} \le {m\choose 2}\max_{i \ne j}c_{ij}.$$ These two inequalities combine to the required result. $\blacksquare$

Note that when $m$ is significantly larger than $k$, the inequality of lemma 1 is far from tight (because the row-wise count is loose). Nevertheless, the above is all we need.

Lemma 2 For natural numbers $k, m$, let $A^1, A^2, \ldots$ be an infinite sequence of $m$-tuples whose values belong to a $k$-element set. For any natural number $l$, and $i, j$, with $1 \le i, j \le m$, let $c^l_{ij}$ be the number of $l'$ with $1 \le l' \le l$, for which $A^{l'}_i = A^{l'}_j$. Suppose that for all such $i, j$, $\lim_{l \to \infty}\limits c^l_{ij}/l = p_{ij}$ exists. Then if $k < m$, there exist $i, j$ with $i \ne j$, such that: $$p_{ij} \ge \frac{1}{m \choose 2}.$$

Proof (sketch) There is a straightforward proof by contradiction based on lemma 1. $\blacksquare$

Lemma 3 For natural numbers $k, m$, let $B^1, B^2, \ldots$ be an infinite sequence of $2 \times m$ matrices whose values belong to a $k$-element set. For any natural number $l$, and $i, j$, with $1 \le i, j \le m$, let $c^l_{ij}$ be the number of $l'$ with $1 \le l' \le l$, for which $B^{l'}_{1i} = B^{l'}_{2j}$ (i.e., the value in column $i$ of the top row of $B^{l'}$ matches the value in column $j$ of the bottom row). Suppose that for all such $i, j$, $\lim_{l \to \infty}\limits c^l_{ij}/l = p_{ij}$ exists and suppose that $p_{ii} = 1$ for $1 \le i \le m$. Then if $k < m$, there exist $i, j$ with $i \ne j$, such that: $$p_{ij} \ge \frac{1}{m \choose 2}.$$

Proof (sketch) Pass to the subsequence of $B$ where all values in the top row match the corresponding values in the bottom row. Since $p_{ii} = 1$, the corresponding limits for this subsequence exist and take the same values as those for $B$. Now apply lemma 2 to the subsequence, viewed as a sequence of $m$-tuples. $\blacksquare$

References

There is an enormous literature on this subject but it is enjoyable to read some of the original papers. I especially liked reading Bell and Mermin.
1. [pdf] Bell, J. S., "On the Einstein Podolsky Rosen paradox" Physics Physique Физика 1(3), pp. 195-200, (1964).
2. [pdf] Bohr, N., "Can Quantum-Mechanical Description of Physical Reality Be Considered Complete?" Phys. Rev., 48, pp. 696-702, (1935).
3. [pdf] Einstein, A., Podolsky, B., and Rosen, N., "Can Quantum-Mechanical Description of Physical Reality Be Considered Complete?" Phys. Rev., 47, pp. 777-780, (1935).
4. [pdf] Mermin, N.D., "Bringing home the atomic world: Quantum mysteries for anybody", Am. J. Phys. 49(10), pp. 940-943, (1981).
5. [pdf] Tsirelson, B.S., "Quantum generalizations of Bell's inequality", Lett. Math. Phys. 4, pp. 93-100, (1980).
